Node&RabbitMQ系列六保证消费

夫大人者，与天地合其德，与日月合其明，与四时合其序，与鬼神合其吉凶。（《周易·䷀乾·文言》）

上篇文章主要以生产者角度：确保消息发出去了，这篇文章主要以消费者的角度：确保处理了对应的消息

处理包含几层含义

成功ack;
失败nack-requeue: true or false;
扔到死信队列

试想以下场景

消费者收到消息，业务执行异常, 重试N次，如果N次内成功–[ack]; 否则丢弃或扔到死信队列;

github上问了该问题,博主的回答

Use a quorum queue (requires RabbitMQ 3.8.0 or higher) and specify a redelivery limit
Count message redeliveries in an external store (you need a unique way to identify the message if you do this)
Instead of nacking the message, re-publish it with a new header which counts the number of redeliveries, then acknowledge the original. This can lead to duplicate messages if you application crashes between the publish and the acknowledgment however

quorum-queue: 设置delivery-limit;
重新publish;
1. 生成header头retrynumbuer;
2. 发布到原来的交换机
3. 丢弃消息
比如采用redis记录重试次数，

Quonum Queue

RabbitMQ–Quorum Queues

Quorum Queues 也是RabbitMQ的队列类型，自RabbitMQ 3.8.0起可用。默认生成的queue type 是 Classic;

宗旨为：将数据安全放在首位
Classic VS Quorum

Feature	Classic Mirrored	Quorum
Non-durable queues <可以非持久>	yes	no
Exclusivity	yes	no
Per message persistence	per message	always
Membership changes	automatic	manual
TTL	yes	no
Queue length limits	yes	partial (drop-head strategy only)
Lazy behaviour	yes	partial (see Memory Limit)
Message priority<优先级>	yes	no
Consumer priority<优先级>	yes	no
Dead letter exchanges	yes	yes
Adheres to policies<策略>	yes	partial (dlx, queue length limits)
Reacts to memory alarms	yes	partial (truncates log)
Poison message handling	no	yes
Global QoS Prefetch	yes	no

Poison message handling: 翻译成异常消息处理，估计没啥问题。

不适用场景

临时队列；
低延迟；
数据安全性没那么高的
非常长的队列—因为quonum一直将数据存储在内存，如可以最大的消息数量、限制消息体的大小。

适用场景
对数据安全性要求高的，例如销售系统中的接收订单或选举系统中的投票，其中可能丢失的消息将对系统的正确性和功能产生重大影响。
发布者确认收到，消费者手动ack, 配合quonum保证数据安全性。

代码实现

// send.ts
import * as amqp from 'amqplib'

(async function publish() {
    const url = `amqp://localhost:5672`;
    // 默认交换机-队列-路由
    const exchange = '6.delivery.limit.exchange';
    const queueExName = '6.delivery.limit.queue';
    const routingKey = '6.delivery.limit.routerkey';


    const connect = await amqp.connect(url);
    const channel = await connect.createChannel();
    // 默认交换机
    await channel.assertExchange(exchange, 'direct', { durable: false });
    // 发布消息
    channel.publish(exchange, routingKey, Buffer.from('hello world'), {
        expiration: 3000
    });
    await sleep(1);
    await connect.close();
    process.exit(0);
})();

function sleep(time: number) {
    return new Promise((resolve) => setTimeout(resolve, time*1000));
}

import * as amqp from 'amqplib'

/**
 * 消费者 确认消息
 *
 * 1. 消费者重试3次，《采用quonum queue + delivery-limit: 3》
 * 2.
*/

(async function consumer() {

    // 交换机-路由
    const url = `amqp://localhost:5672`;
    // 死信交换机-路由
    const deadLetterExchange = '6.dlx.exchange';
    const deadLetterRoutingKey = '6.dlx.routingkey'
    const deadLetterQueue = '6.dlx.queue'
    // 默认交换机-队列-路由
    const exchange = '6.delivery.limit.exchange';
    const queueExName = '6.delivery.limit.queue';
    const routingKey = '6.delivery.limit.routerkey';


    const connect = await amqp.connect(url);
    const channel = await connect.createChannel();
    await channel.assertExchange(exchange, 'direct', { durable: false });

    // 死信队列相关，为了web ui 展示数据
    await channel.assertExchange(deadLetterExchange, 'direct', { durable: false });
    const queueDL = await channel.assertQueue(deadLetterQueue)
    await channel.bindQueue(queueDL.queue, deadLetterExchange, deadLetterRoutingKey);


    const queueEX = await channel.assertQueue(queueExName, {
        exclusive: false,
        deadLetterExchange,
        deadLetterRoutingKey,
        arguments: {
            'x-queue-type': 'quorum',
            'x-delivery-limit': 3
        }
    });
    await channel.bindQueue(queueEX.queue, exchange, routingKey);
    await channel.consume(queueEX.queue, msg => {
        console.log("消费队列", msg);
        channel.nack(msg, false, true)
    });
})();

➜  6Consumer git:(main) ✗ ts-node receive.ts
消费队列 { fields:
   { consumerTag: 'amq.ctag-EKH-xj09f47rsz3EqX8e7Q',
     deliveryTag: 1,
     redelivered: false,
     exchange: '6.delivery.limit.exchange',
     routingKey: '6.delivery.limit.routerkey' },
  properties:
   { contentType: undefined,
     contentEncoding: undefined,
# 这里
     headers: {},
     deliveryMode: undefined,
     priority: undefined,
     correlationId: undefined,
     replyTo: undefined,
     expiration: '3000',
     messageId: undefined,
     timestamp: undefined,
     type: undefined,
     userId: undefined,
     appId: undefined,
     clusterId: undefined },
  content: <Buffer 68 65 6c 6c 6f 20 77 6f 72 6c 64> }
消费队列 { fields:
   { consumerTag: 'amq.ctag-EKH-xj09f47rsz3EqX8e7Q',
# 看这里
     deliveryTag: 2,
     redelivered: true,
     exchange: '6.delivery.limit.exchange',
     routingKey: '6.delivery.limit.routerkey' },
  properties:
   { contentType: undefined,
     contentEncoding: undefined,
# 这里
     headers: { 'x-delivery-count': 1 },
     deliveryMode: undefined,
     priority: undefined,
     correlationId: undefined,
     replyTo: undefined,
     expiration: '3000',
     messageId: undefined,
     timestamp: undefined,
     type: undefined,
     userId: undefined,
     appId: undefined,
     clusterId: undefined },
  content: <Buffer 68 65 6c 6c 6f 20 77 6f 72 6c 64> }
消费队列 { fields:
   { consumerTag: 'amq.ctag-EKH-xj09f47rsz3EqX8e7Q',
     deliveryTag: 3,
     redelivered: true,
     exchange: '6.delivery.limit.exchange',
     routingKey: '6.delivery.limit.routerkey' },
  properties:
   { contentType: undefined,
     contentEncoding: undefined,
     headers: { 'x-delivery-count': 2 },
     deliveryMode: undefined,
     priority: undefined,
     correlationId: undefined,
     replyTo: undefined,
     expiration: '3000',
     messageId: undefined,
     timestamp: undefined,
     type: undefined,
     userId: undefined,
     appId: undefined,
     clusterId: undefined },
  content: <Buffer 68 65 6c 6c 6f 20 77 6f 72 6c 64> }

简单即是美
